Lubricating Concrete Batching Plant Parts Electric Grease Pump 6L

Minimum Order Quantity1
Packaging DetailsExport standard packing 480*200*200m
Payment TermsD/P, T/T
Place of OriginChangsha, Hunan, China
Model Number4WDB-M1.2/244F
Price$370
Delivery Time7 work days
Supply Ability100 pcs/month
Brand NameChangsha Tongchuang Mechanical
Detail Information
Name:Electric Lubricating PumpProduct Name:Lubrication Pump, Electric Lubrication Pump, Electric Thick Oil Pump, Electric Grease Pump
Applicable Model:Mixing Hosts Brand Such As Sany, Zoomlion , Nanfang Road Machine, SICOMA, Etc.Specifications And Models:4WDB-M1.2/244F
Specification Size:480*200*200mmWeight:7.5KG
Oil Drum Volume:6LVoltage:DC24V
Quantity Of Output Port:4Rated Displacement:1.2-2.0ml/min
Nominal Pressure:25MPaUse:Provide Lubricating Grease For Shaft End Of Concrete Mixer.
High Light:Lubricating Concrete Batching Plant Parts, Concrete Batching Plant Parts Grease Pump, Electric Grease Pump 6L

Product Description

The lubrication pump of concrete batching plant parts​

The lubrication pump of concrete batching plant parts
NameElectric lubricating pump
Product nameLubrication Pump, Electric Lubrication Pump, Electric Thick Oil Pump, Electric Grease Pump
Place of originChangsha, Hunan, China
Brand nameChangsha Tongchuang Mechanical
Applicable modelMixing hosts Brand such as Sany, Zoomlion , Nanfang Road Machine, SICOMA, etc.
Specifications and models4WDB-M1.2/244F
Specification size480*200*200mm
Weight7.5KG
Oil drum volume6L
VoltageDC24V
Quantity of Output port4
Rated displacement1.2-2.0ml/min
Nominal pressure25MPa
UseProvide lubricating grease for shaft end of concrete mixer.
Supply capacity100 Pieces/month
PackingExport standard packing 480*200*200mm
Minimum order1pcs
Price$370

Product features and advantages:

1, The pump components are modularized, and various combinations are made according to the actual working conditions, so that the failure of a single pump component does not affect the grease outlet at other points.
2, Transparent resin oil drums are convenient for observing the grease storage capacity.
3, The pump components at each grease outlet are equipped with safety relief valves and pressure gauges. So as to monitor the working condition of lubricating points and lubricating pumps at any time.
4, Fully sealed structure of lubricating pumps, suitable for outdoor working conditions, waterproof and dustproof functions, suitable for forging, construction machinery, rubber and plastic, chassis and other equipment.
5, Equipped with built-in program controller, each grease outlet can be directly connected to lubricating points, or can be independently connected to progressive distributors.

Maintenance method:

1, Every time you add grease, it is advisable to inject a small amount of mechanical oil first, so that the air in the filter screen can be discharged.
2, In case of pump pressure loss or low pressure, please clean the safety relief valve or oil outlet check valve.
